Sundown Audio E-Series V.4 12” Subwoofer
Free Shipping In The Contiguous United States
Free Shipping In The United States, excluding Alaska and Hawaii.
International Shipping available and calculated at checkout.
Description
- 750 Watts RMS / 1500 Watts Peak
- Dual 2 or 4 ohm voice coils
- Optimized for ported enclosures
- Class-leading 14mm Xmax
- Double-stacked magnet
- Vented magnetic gap & pole piece for superior cooling
- High strength stamped steel frame
- High temp 4-layer copper voice coil wire
- High-quality push terminals
- Stitched-on Mini-XL tinsel leads
Through relentless research in our North Carolina Headquarters, Sundown optimized a 2.5” voice coil and a truly unique motor design to get the deepest possible bass response out of a 10” subwoofer.
The subwoofer showcases a distinctive motor design, featuring a heavily vented magnetic gap and solid pole piece, enabling exceptional thermal power handling. The spider itself is a high strength poly-cotton blend designed to handle the full capacity of the motor. To provide an additional level of ruggedness the spider is bolted down and glued to the frame. Its motor geometry allows for a remarkable 14mm one-way linear Xmax, delivering excursion equivalent to far larger cones.
Specifications
| T/S Specs |
E v.4 12" D2 |
E v.4 12" D4 |
|---|---|---|
| RE (Ohms) | 4.030 | 6.130 |
| FS (Hz) | 28.480 | 28.373 |
| VAS (L) | 53.059 | 54.292 |
| Qes | 0.509 | 0.570 |
| Qms | 5.249 | 3.542 |
| Qts | 0.464 | 0.491 |
| BL (NA) | 17.576 | 20.249 |
| Mms (Grams) | 217.987 | 213.033 |
| Cms (mm/N) | 143.258 | 146.589 |
| Sens (dB @ 1w/1m) | 85.7 | 85.3 |
| Xmax | 14mm | 14mm |
Enclosure Specs
- Ported Enclosure
- Size: 1.75 cu. ft. net
- Port Area: 26 sq. in.
- Port Tuning: 35 Hz
- Sealed Enclosure
- Not Recommended
- Displacement: 0.12 cu. ft.
- Depth: 6.50"
- Outside Diameter: 12.250"
- Cutout: 11.125"
