Horizon HZ 12" Subwoofer
Free Shipping In The Contiguous United States
Free Shipping In The United States, excluding Alaska and Hawaii.
International Shipping available and calculated at checkout.
Description
HZ Series Key Features:
- RMS Power:
- 12" – 750W RMS / 2.5" Voice Coil
- Voice Coil Options: Dual 4Ω - High temp 4-layer copper voice coil wire
- XMAX: Class-leading 14mm Xmax
- Frame: Heavy-duty cast aluminum basket
- Cooling: Vented motor gap and pole piece for optimized heat dissipation
- Durability: Stitched Mini-XL tinsel leads and bolted spider pack
- Suspension: High-roll surround with progressive spider for smooth, controlled excursion
- Recommended Enclosure: Ported for maximum efficiency and output
Specifications
RE (Ohms) |
6.130 |
FS (Hz) |
31.696 |
VAS (L) |
54.368 |
Qes |
0.598 |
Qms |
3.774 |
Qts |
0.516 |
BL (NA) |
18.731 |
Mms (Grams) |
171.761 |
Cms (mm/N) |
146.795 |
Sens (dB @ 1w/1m) |
86.5 |
Xmax |
14mm |
T/S SPECS |
HZ 12" |
Enclosure Specs
-
-
Ported Enclosure
- Size: 1.75 cuft net
- Port Area: 26 sq in
- Port Tuning: 35hz
-
Sealed Enclosure
- Size: 1.0 cuft net
- Displacement: 0.12 cuft.
- Depth: 6.3"
- Outside Diameter: 12.5"
- Cutout: 11.2"
-
