Sundown Audio U-Series 8" Subwoofer D2/D4

Description

    • 750W Watts RMS / 1500 Watts Peak
    • Dual 2 or 4 ohm voice coils
    • Optimized for small ported enclosures
    • Aluminum 2.25” voice coil former for superior heat dissipation
    • High-temperature copper voice coil
    • Double stitched surround
    • Heavy-duty cast basket
    • Spring-loaded terminals accept up to 8-gauge wire
    • Stitched-on heavy-duty tinsel leads
    • Solid pole with vent channels and aluminum shorting ring cap
    • Rear gap-venting
    • Top-Plate Cooling Channels

    The U-8 can be thought of as an SA-8 v3 on performance boosters. Everything there is to love about the SA-8 v3 just with more power handling, more x-max, and more output potential.

    The specially designed motor is mated to a custom tooled and patented (US Patent D691595) frame which allows for a larger spider and superior clearances to nearly any other 8" woofer on the market today. The U-8 features a full 18mm of one-way linear excursion and mechanical capacity in excess of double the linear limits (around 2.5” peak-to-peak) to ensure that mechanical failures are nearly impossible. As with the SA-8 v.3 it features a surround that mimics the geometry of our large Mega-Roll v.2 surrounds for incredible linearity.

    Sundown Audio U-Series 8" Subwoofer D2/D4

    Product form

    750W Watts RMS / 1500 Watts Peak Dual 2 or 4 ohm voice coils Optimized for small ported enclosures Aluminum... Read more

    $349.99

      • Free shipping in the contiguous USA on all orders above $99
      • Full Manufacturer Warranty On All Items
      • No Hassle, Easy 30 Day Returns
      • Price Match Guarantee. Lowest Prices Anywhere.
      • REAL Audio Enthusiasts, Expert Support
      SpecificationU8v1 D2U8v1 D4
      Fs39.39 Hz41.29 Hz
      Re3.80 Ω6.34 Ω
      Qms2.47402.5420
      Qes0.41200.5190
      Qts0.35300.4310
      Mms175.34 g145.24 g
      Cms93.13 µm/N102.31 µm/N
      Sd344.8 cm²344.8 cm²
      Vas6.35 L6.97 L
      Sensitivity81.6 dB82.7 dB
      BL20.000 T·m21.450 T·m
      X-Max18 mm18 mm
      RMS Power750 W750 W
      Peak Power1500 W1500 W
      SpecificationU8v1 D2/D4
      Overall Diameter8.70"
      Cutout Diameter7.375"
      Motor Diameter6.88"
      Mounting Depth6.02"
      Displacement0.09 Cu. Ft.
      Sealed Volume0.25-0.35 cu ft
      Ported Volume0.65 cu ft
      Port Tuning35 Hz
      Port Area9 sq in
      4th Order Sealed0.225 cu ft
      4th Order Ported0.675 cu ft
      4th Order Port Area14 sq in
      4th Order Port Length6"

      Description

        • 750W Watts RMS / 1500 Watts Peak
        • Dual 2 or 4 ohm voice coils
        • Optimized for small ported enclosures
        • Aluminum 2.25” voice coil former for superior heat dissipation
        • High-temperature copper voice coil
        • Double stitched surround
        • Heavy-duty cast basket
        • Spring-loaded terminals accept up to 8-gauge wire
        • Stitched-on heavy-duty tinsel leads
        • Solid pole with vent channels and aluminum shorting ring cap
        • Rear gap-venting
        • Top-Plate Cooling Channels

        The U-8 can be thought of as an SA-8 v3 on performance boosters. Everything there is to love about the SA-8 v3 just with more power handling, more x-max, and more output potential.

        The specially designed motor is mated to a custom tooled and patented (US Patent D691595) frame which allows for a larger spider and superior clearances to nearly any other 8" woofer on the market today. The U-8 features a full 18mm of one-way linear excursion and mechanical capacity in excess of double the linear limits (around 2.5” peak-to-peak) to ensure that mechanical failures are nearly impossible. As with the SA-8 v.3 it features a surround that mimics the geometry of our large Mega-Roll v.2 surrounds for incredible linearity.
