Stereo Integrity SIQ 75.4 High-Fidelity 4-Channel Amplifier

Description

Stereo Integrity SIQ 75.4 Amplifier: Purity at its Finest for Your Soundstage



The Stereo Integrity SIQ 75.4 signals the return of true high-fidelity audio engineering to the mobile sound space. Built by audiophiles for the most discerning listeners, this 4-Channel Class A/B amplifier prioritizes signal integrity above all else. Its core design features zero filters, zero crossovers, and zero EQ, delivering a full bandwidth signal (5 Hz to 150,000 Hz) that is clean, precise, and uncompromised. This is the foundation for an accurate soundstage and breathtaking sonic detail.

Uncompromised Audiophile Construction

Every component in the SIQ 75.4 was selected for its acoustic performance and durability:

  • Output Transistors: Utilizes audiophile-grade TO-3 output transistors for clean, linear power.

  • Internal Circuitry: Features high-quality UPC4570 op-amps, IRFPO64N power supply transistors, and sand cast resistors throughout.

  • Connections: Equipped with premium Tiffany-style RCA connections accepting inputs up to 16 Volts.

  • Chassis: Protected by a thick extruded aluminum chassis with a copper anodized shielded transformer cover to minimize electromagnetic interference, all visible through a large plexiglass viewing window.

Clean Power, Ultra-Low Distortion Performance

The SIQ 75.4 delivers precise power with unmatched fidelity, validated by Audio Precision measurements:

  • Rated RMS Power Output (4 Channels): 75W RMS x4 @ 4Ω

  • High Current Output: 120W RMS x4 @ 2Ω

  • Bridged Power: 120W RMS x2 @ 4Ω

  • Total Harmonic Distortion (THD): An ultra-low 0.03 %

  • Signal-to-Noise Ratio (SNR): 90 dB

Installation and Specifications

  • Purity Control: Features a discrete gain knob per channel for precise level matching.

  • Dimensions: Compact size at 14 x 8 x 2 Inches.

  • Current Draw: Maximum current draw of 66 amps.

The SIQ 75.4 is the ideal solution for audiophiles seeking true sound reproduction for their front and rear stage speakers.

Amplifiers Specifications

Frequency Response Minimum 5 Hz
Frequency Response Maximum

150,000 Hz
Signal-to-Noise Ratio (SNR) 90 dB
Total Harmonic Distortion (THD) 0.03 %
Dimensions (W x H x D) 14 x 8 x 2 Inches
Rated RMS power output into all 4 channels at 4 ohm 75 Watts
Rated RMS power output into all 4 channels at 2 ohm 120 Watts
Bridged RMS power into 2 channels at 4 ohm 120 Watts



Power

Idle Current Draw 1.2 amps
Maximum Current Draw 66 amps




Connections

RCA Input Maximum 16 Volts

Stereo Integrity SIQ 75.4 High-Fidelity 4-Channel Amplifier

Product form

Stereo Integrity SIQ 75.4 Amplifier: Purity at its Finest for Your Soundstage   The Stereo Integrity SIQ 75.4 signals the return of... Read more

$379.00

    • Free shipping in the contiguous USA on all orders above $99
    • Full Manufacturer Warranty On All Items
    • No Hassle, Easy 30 Day Returns
    • Price Match Guarantee. Lowest Prices Anywhere.
    • REAL Audio Enthusiasts, Expert Support

    Description

    Stereo Integrity SIQ 75.4 Amplifier: Purity at its Finest for Your Soundstage



    The Stereo Integrity SIQ 75.4 signals the return of true high-fidelity audio engineering to the mobile sound space. Built by audiophiles for the most discerning listeners, this 4-Channel Class A/B amplifier prioritizes signal integrity above all else. Its core design features zero filters, zero crossovers, and zero EQ, delivering a full bandwidth signal (5 Hz to 150,000 Hz) that is clean, precise, and uncompromised. This is the foundation for an accurate soundstage and breathtaking sonic detail.

    Uncompromised Audiophile Construction

    Every component in the SIQ 75.4 was selected for its acoustic performance and durability:

    • Output Transistors: Utilizes audiophile-grade TO-3 output transistors for clean, linear power.

    • Internal Circuitry: Features high-quality UPC4570 op-amps, IRFPO64N power supply transistors, and sand cast resistors throughout.

    • Connections: Equipped with premium Tiffany-style RCA connections accepting inputs up to 16 Volts.

    • Chassis: Protected by a thick extruded aluminum chassis with a copper anodized shielded transformer cover to minimize electromagnetic interference, all visible through a large plexiglass viewing window.

    Clean Power, Ultra-Low Distortion Performance

    The SIQ 75.4 delivers precise power with unmatched fidelity, validated by Audio Precision measurements:

    • Rated RMS Power Output (4 Channels): 75W RMS x4 @ 4Ω

    • High Current Output: 120W RMS x4 @ 2Ω

    • Bridged Power: 120W RMS x2 @ 4Ω

    • Total Harmonic Distortion (THD): An ultra-low 0.03 %

    • Signal-to-Noise Ratio (SNR): 90 dB

    Installation and Specifications

    • Purity Control: Features a discrete gain knob per channel for precise level matching.

    • Dimensions: Compact size at 14 x 8 x 2 Inches.

    • Current Draw: Maximum current draw of 66 amps.

    The SIQ 75.4 is the ideal solution for audiophiles seeking true sound reproduction for their front and rear stage speakers.

    Amplifiers Specifications

    Frequency Response Minimum 5 Hz
    Frequency Response Maximum

    150,000 Hz
    Signal-to-Noise Ratio (SNR) 90 dB
    Total Harmonic Distortion (THD) 0.03 %
    Dimensions (W x H x D) 14 x 8 x 2 Inches
    Rated RMS power output into all 4 channels at 4 ohm 75 Watts
    Rated RMS power output into all 4 channels at 2 ohm 120 Watts
    Bridged RMS power into 2 channels at 4 ohm 120 Watts



    Power

    Idle Current Draw 1.2 amps
    Maximum Current Draw 66 amps




    Connections

    RCA Input Maximum 16 Volts
