Description
What You Can Expect
Engineered in the USA, LX can effortlessly serve the needs of car-audio systems that require premium amplification, high power, system design flexibility, DSP-powered features, and the ability to monitor and control it all remotely. It’s the perfect marriage of SQL design and high-powered output.
Eliminate Unwanted Noise
All seven models utilize FIT+™ (Fail-safe Integration Technology-PLUS), accepting low- and high-level signals up to 40V, with full differential inputs created to eliminate noise that would ruin your sound. All feature the choice of turn-on mode and comprehensive protections for thermal, circuit, and voltage stability, ensuring reliable performance.
For the Bass
LX features a choice of four very efficient, compact, high-power monoblock amps ranging from 850 to 3000 watts all 1-Ohm stable, with a chassis less than nine inches deep and about a foot or less wide. They’re very easy to install in any application.
All-In-One Power Tool
We got those too! A full-range, 4-channel amplifier, a 5-channel multi-channel hybrid with subwoofer section, and an innovative 7-channel multi-channel hybrid with sub section complete the lineup.
LXRC with Models that Make Bass
Six amps with mono channels come with the LXRC (LX Remote Control), giving you dynamic fingertip dash direction of bass level. It features SHOCwave2.0™ (Sub-Harmonic Octave Creation), KICKER’s 2nd-gen digital bass restoration algorithm that recovers lost, low-bass frequencies vital to your music selections. It also displays battery voltage in a fuel-gauge-style readout, control of its RGB LED brightness, and output clipping indication.
| LX 3000.1 white paper |
| 51LX30001 Whitepaper PDF |
| RMS Power [Watts Channel] @ 14.4V |
1Ω mono: 3000W
2Ω mono: 2000W
4Ω mono: 1100W |
| Dynamic Power [Watts] |
| 3800 |
| Frequency Response [Hz] |
| 10–160, +0/–1dB |
Signal-to-Noise Ratio
(a-weighted, re: rated power) |
| >95dB |
Signal-to-Noise Ratio
(ref: 1W output) |
| >75dB |
| Dimensions [in, cm] |
Height: 2-3/8 (6 cm) Width: 8-7/16 (21.4 cm)
Length: 12-5/8 (32 cm) |
| Input Sensitivity |
High level 1V–40V
Low level 125mV–5V |
| Variable Electronic Crossover |
LP; 24dB/octave Linkwitz-Riley,
variable 40–160Hz |
| Variable Subsonic Filter |
24dB/octave Linkwitz-Riley,
variable hi-pass @ 10–80Hz |
| KickEQ+™ Parametric Bass Boost |
0–6dB, variable center 20–80Hz,
variable bandwidth 1–5 |
| Warranty |
| When purchased from an Authorized KICKER Dealer or kicker.com, KICKER warrants this product to be free from defects in material and workmanship under normal use for a period of TWO (2) YEARS from date of original purchase. |
