LX1300.7: The Masterpiece of Complete System Integration
The KICKER LX1300.7 is the crown jewel of the LX-Series, offering an unprecedented 7-channel solution designed to power an entire high-fidelity ecosystem from a single, sophisticated chassis. Engineered for "Sound Quality Loud" (SQL) performance, this powerhouse features four high-output channels for your primary stage (125W x 4), two additional channels perfect for rear fill or smaller drivers (65W x 2), and a dedicated mono-block section pushing up to 700W to your subwoofers. Utilizing an elite Class-D design, the LX1300.7 delivers massive multi-channel authority while maintaining the thermal stability and efficiency required for high-end automotive installs.
Precision is at the heart of the LX1300.7 experience. The included LX Control Center (LXCC) provides a wired diagnostic and tuning hub directly at the amplifier, allowing you to monitor battery voltage, temperature, and clipping in real time while incrementally dialing in gain trim and time delay. For the driver, the LX Remote Control (LXRC) provides fingertip command over bass levels and features SHOCwave 2.0™—KICKER’s advanced digital restoration algorithm that breathes life back into low-frequency signals. Whether you are running a complex 3-way active front stage or a full cabin surround system, this amplifier provides the flexibility and power to handle it all.
Built to withstand the rigors of high-performance audio, the LX1300.7 features FIT+™ technology to ensure a crystal-clear signal even in vehicles with complex factory electrical systems. The aesthetic is completely customizable, featuring a reversible center panel and 11 selectable RGB LED accent colors to match your custom build. With comprehensive protection circuitry and precision-engineered Linkwitz-Riley crossovers, the LX1300.7 isn't just an amplifier—it's the definitive command center for a world-class mobile audio experience.
51LX13007 Whitepaper PDF
TECHNICAL SPECIFICATIONS
| LX1300.7 MULTI-CHANNEL SYSTEM PERFORMANCE |
| RMS Power (Amp 1 & 2) |
125W x 4 @ 4Ω / 150W x 4 @ 2Ω |
| RMS Power (Amp 3 Pair) |
65W x 2 @ 4Ω or 2Ω |
| RMS Power (Sub Channel) |
700W x 1 @ 1Ω / 550W x 1 @ 2Ω |
| Bridged Power (Ch 1-4) |
250W x 2 @ 4Ω |
| Dynamic Power |
1500 Watts |
| Frequency Response |
20Hz–20kHz (Stereo) / 10Hz–160Hz (Sub) |
| Signal-to-Noise Ratio |
>95 dB (a-weighted) |
DUAL COMMAND INTERFACE (LXCC & LXRC)
| DIAGNOSTICS & TUNING FEATURES |
| Bass Restoration |
SHOCwave 2.0™ (Sub-Harmonic Octave Creation) |
| Real-Time Monitoring |
Voltage, Temperature, & Protection Status |
| Precision Controls |
Gain Trim, Time Delay, & Selectable Crossover Slopes |
| Crossover Types |
HP / LP / BP (High, Low, and Bandpass) |
| Remote Cable Length |
19.75 feet (6m) RJ45 for LXRC |
DESIGN & DIMENSIONS
| PHYSICAL SPECIFICATIONS |
| Height |
2-3/8 in (6 cm) |
| Width |
8-7/16 in (21.4 cm) |
| Length |
12-5/8 in (32 cm) |
| Accent Lighting |
11 Selectable RGB LED Colors |
| Warranty |
2 Years (Authorized Dealer) |
