Description
LX1200.5: The Ultimate All-in-One SQL Powerhouse
The KICKER LX1200.5 is the definitive solution for audiophiles seeking a complete, high-performance system overhaul from a single chassis. This 5-channel titan combines the surgical precision of the LX-Series full-range channels with a dedicated, high-current mono subwoofer section. Delivering 125W x 4 + 700W x 1 (at 4Ω/1Ω), it provides the "Sound Quality Loud" (SQL) performance KICKER is famous for. Built with advanced Class-D technology, this amplifier ensures massive output with a smaller footprint, lower operating temperatures, and reduced current draw from your vehicle's charging system.
Total system command is achieved through a dual-interface approach. The included LX Control Center (LXCC) provides real-time diagnostic readouts and precision tuning—including time delay and complex crossover configurations—directly at the amplifier. For the driver, the LX Remote Control (LXRC) dash unit offers fingertip access to subwoofer levels and the legendary SHOCwave 2.0™ bass restoration. Whether you’re recovering lost low-end frequencies from digital files or monitoring your battery voltage via the fuel-gauge display, the LX1200.5 keeps you in total control of your acoustic environment.
Designed for seamless integration into complex modern vehicles, the LX1200.5 features FIT+™ technology, accepting signals up to 40V while maintaining a noise-free floor. Its aesthetic is as customizable as its sound, featuring a reversible center panel and 11 selectable RGB LED accent colors. From its comprehensive thermal and circuit protections to the variable KickEQ+™ parametric boost, every inch of this amplifier is built to deliver a lifetime of elite, concert-level audio.
51LX12005 Whitepaper PDF
TECHNICAL SPECIFICATIONS
| LX1200.5 5-CHANNEL SYSTEM PERFORMANCE |
| RMS Power (Channels 1-4) |
125W x 4 @ 4Ω / 175W x 4 @ 2Ω |
| RMS Power (Sub Channel) |
700W x 1 @ 1Ω / 550W x 1 @ 2Ω / 300W x 1 @ 4Ω |
| Bridged Power (Ch 1-4) |
350W x 2 @ 4Ω |
| Dynamic Power |
1500 Watts |
| Frequency Response |
20Hz–20kHz (Stereo) / 10Hz–160Hz (Sub) |
| Signal-to-Noise Ratio |
>95 dB (a-weighted) |
| Input Sensitivity |
High Level: 1V–40V / Low Level: 125mV–5V |
CONTROL & BASS RESTORATION
| LXCC & LXRC DUAL INTERFACE FEATURES |
| Bass Restoration |
SHOCwave 2.0™ (Sub-Harmonic Octave Creation) |
| Precision Tuning |
Time Delay, Gain Trim, & Selectable Crossover Slope |
| Real-Time Monitoring |
Battery Voltage, Temperature, & Clipping LEDs |
| Crossover Types |
HP / LP / BP (High, Low, and Bandpass) |
| Subsonic Filter |
24dB/oct, Variable 10–80Hz (Sub Channel) |
DIMENSIONS & DESIGN
| PHYSICAL SPECIFICATIONS |
| Height |
2-3/8 in (6 cm) |
| Width |
8-7/16 in (21.4 cm) |
| Length |
12-5/8 in (32 cm) |
| Accent Lighting |
11 Selectable RGB LED Colors |
| Warranty |
2 Years (Authorized Dealer) |
