Description
Product Overview: Audio Ace’s Powerful and Versatile 18-Inch Driver
The Audio Ace Jester 18" D2 is designed to achieve a high level of both Sound Quality (SQ) and Sound Pressure Level (SPL), rated at a strong 3,000W RMS. Its design includes a fairly low Free Air Resonance (Fs) and a powerful motor structure, making it highly versatile for great sound across a wide range of music. Whether you're aiming for extreme sound levels in your daily driver or looking to be one of the loudest vehicles in your town, the Jester is a great choice. It features a heavy-duty die-cast aluminum basket, a 3-inch BACCAW 4-layer voice coil, a 300 oz magnet structure, and a 4-layer 10-inch spider suspension.
| AUDIO ACE JESTER 18" DUAL 2 OHM SPECIFICATIONS |
| Model |
Jester 18" |
| RMS Power Handling |
3,000 Watts |
| Voice Coil |
3" BACCAW 4 Layer Coil |
| Magnet Structure |
300 oz |
| Suspension |
4 Layer 10" Spider |
| Basket |
Heavy Duty Die Cast Aluminum |
| Nominal Impedance |
Dual 2 Ohm (D2) |
| Cutout Diameter |
16.85 in |
| Mounting Depth |
11.10 in |
| LOSS FACTORS & MISC PARAMETERS |
| Total Q (Qts) |
0.550 |
| Mechanical Q (Qms) |
6.006 |
| Electrical Q (Qes) |
0.605 |
| Free Air Resonance (Fs) |
29.2 Hz |
| Sensitivity (Lm) |
87.30 dB |
| Equivalent Volume (Vas) |
81.8396 L |
| Moving Mass (Mms) |
703.831 g |
| BL Factor (Bl) |
27.457 |
| DC Resistance (Re) |
3.53 Ohms |
