Incriminator Audio Flatlyne FL15D2 15" 600W RMS Dual-2-Ohm Car Subwoofer/Sub

Original price $429.00 - Original price $429.00
Original price
$429.00
$429.00 - $429.00
Current price $429.00

Description

Incriminator Audio has been known for years to be a company dedicated to SPL. It is no secret that IA products have won numerous world records in the SPL lanes, and are all designed to be able to handle the extreme stress an SPL vehicle places on a product. The goal of the IA Flatlyne subwoofer was to crush all the rumors of IA only producing SPL products. The Flatlyne is an under-hung sound quality based subwoofer that will reproduce low octave tones with unmatched accuracy.

Features

  • 8 Spoke Black Cast Basket
  • 3" 8 Layer Round Copper Voice Coil
  • Dual Black Progressive Spiders with Woven Tinsel Leads
  • Injected Pulp Matrix Fiber Reinforced Cone
  • Dual Layer Foam Surround
  • 8" 100 Oz Single Magnet with an Underhung Topology
  • 448 Oz / 28 Pound Motor Structure and Black Nickel Finish
  • Interlocking Aluminum Spider Spacer Assembly
  • CILD² - Center Interlocking Dustcap
  • ADC - Air Driven Cooling
  • Nickel Plated Push Terminals
  • Wrap Around Rubber Gasket
  • 600 Watt RMS Rated
  • DVC 2 ohm or 4 ohm

Specifications

Driver
12 Inch 15 Inch 18 Inch
FS
28 Hz N/A N/A
Re
8Ω Series 8Ω Series 8Ω Series
Qms
3.88 4.58 N/A
Qes
.55 .65 N/A
Qts
.43 .51 N/A
Mms
224 g 296 g N/A
Cms
0.14 mm/N 0.14 mm/N 0.14 mm/N
Sd
480 cm² 810 cm² 1210 cm²
Vas
36.9 L 118 L N/A
Spl
83.7 db 85.8 db N/A
BL
14.6 14.6 14.6
X-max
18 mm 18 mm 18 mm
Sub Diameter
12.37" 15.50" 18.50"
Mounting
11.12" 14.12" 16.87"
Depth
6.75" 7.50" 8.87"
Displacement
.13 Cu. Ft. .15 Cu. Ft. .18 Cu. Ft.
Power
600 RMS 600 RMS 600 RMS
