Hifonics Zeus 3.5 inch 2 way car audio coaxial speaker system with Mylar dome tweeter and Alpha-Cellulose Poly Woofer Cones nylon surrounds (pair). (No Grills).
-
RMS POWER HANDLING (CEA426B)
25 -
MAXX POWER
125 -
SPEAKER IMPEDANCE
4 Ω -
FREQUENCY RESPONSE +/- 3DB
80Hz-20kHz -
SENSITIVITY (1 WATT/1 METER)
88 db -
CROSSOVER POINT
6 khz -
CROSSOVER SLOPE
12dB -
MOUNTING DIAMETER/CUT OUT
3.41 -
OUTSIDE DIAMETER
3.41 No Grill -
MOUNTING DEPTH/CHASSIS DEPTH
1.5 -
DIMENSIONS
9.75 x 5.88 x 3 in -
WEIGHT
2 lbs -
TWEETER DOME MATERIAL:Neo-Mylar Soft Dome Tweeter Impact Resistant Tweeter Elements
-
SURROUND:Rubber Moisture Resistant Rubber Surround with high Mid-Bass Impact
-
CONE:Alpha-Cellulose Cones Light weight for speed and very rigid for deep bass
-
SURROUND / CONE COUPLING:High Temperature Adhesive Special adhesive is chosen to create a permanent bond between the cone and the surround
-
TINSEL LEADS:Braided Highly conductive while remain flexible during high power applications
-
VOICE COIL:Pure Copper Creates strong magnetic field with a very thin extrusion
-
VOICE COIL FORMER:Kapton Lightweight and efficiently dissipates heat
-
SPIDER:Epoxy infused Natural Fiber Natural fiber allows flexibility while the epoxy which gives strength during the manufacturing process.
-
COOLING SYSTEM: Overcoil Air is exchanged over the voice coil through the spider
-
CROSSOVER TYPE: Passive Butterworth Smooth transition of frequencies from midrange/midbass to the tweeter element
-
FRAME TYPE: Anti-Resonant Stamped Steel Basket Very strong with minimal harmonics or distortions from flex or ringing
-
MOTOR: Ferrite Magnet Creates a strong magnetic field while remaining small enough to fit nearly every application
-
CONNECTORS: Spade Use spade connectors or solder direct for the best connection
-
GRILLS: No. These speakers are typically installed behind an OEM panel
-
TWEETER MATERIAL: Neo-Mylar Soft Dome Great sound quality and increased reliability
-
TWEETER SIZE: 1 inch Clear highs while handling plenty of power without sound harsh
-
TWEETER SURROUND MATERIAL: Kapton Lightweight and efficiently dissipates heat
